Document Ref: EMSD Type Approval Technical Appendix
Application No.: BM00007544
Model: Shandong JiuRoad Mechanized Vehicle Parking System PCXC Series
The official technical specifications and mechanical structure of the Shandong JiuRoad Corp PCXC Series Mechanized Vehicle Parking System (MVPS), as approved by the Hong Kong Electrical and Mechanical Services Department (EMSD). This type approval is granted based on the verified certificate of conformity and test reports, signifying full compliance with the European safety standard EN14010.
📋 System Overview & Capacity
- System Type: Mechanized vehicle parking system (MVPS) operating as an automatic parking equipment in a rotary carousel configuration.
- Operating Capacity: The system is designed and approved to accommodate up to 10 or 20 parking spaces per standalone unit.
- Load Carrying Approach: Uses individual load carriers specifically engineered for carrying vehicles safely through the rotary cycle.
⚙️ Mechanical Drive & Transmission Structure
The core kinematics of the PCXC Series rely on a synchronized chain-drive mechanism:
- Primary Motor & Drive Linkage: The MVPS is powered by a vertical lifting motor, which is mechanically connected to the main drive sprocket via a heavy-duty duplex roller drive chain.
- Front & Rear Synchronization:
- The drive sprocket connects directly to the front transmission sprocket to drive the front lifting chain.
- Simultaneously, a drive axle connects to the rear transmission sprocket, which safely sequences and drives the rear lifting chain.
🔀 Rotary Actuation & Motion Restriction
The stability of the load carriers and the restriction of physical sway during cycle rotation are strictly controlled via the following structural designs:
- Suspension Mechanism: Triangular plates are securely attached to both the front and rear lifting chains. These technical components suspend the load carriers and actuate their continuous rotary motion.
- Directional Control Rails: The rollers of the individual load carriers run on precisely engineered guide rails. These rails naturally restrict the direction of movement of the load carriers, ensuring safe horizontal alignment and preventing dangerous mechanical swing during vertical operation.
Note: The exact operating ranges dictated by the make of the machinery and the respective certificate of conformity are strictly aligned with this EMSD-approved application schedule.
